Lab as a Service

The quality of our laboratories have been praised and certified by testing laboratories such as VDE and UL. While the main purpose of our laboratories has been to test our own products, we now offer a broad range of testing services to our customers.

Our lab testing services are performed by the Quality Management (QM) LAB department.

Your benefits

With our new testing services, we want to help customers who do not have an own lab or whose internal resources are limited. By doing the tests with us, you can have a comfortable product and market launch. As we can offer both the components and the design-in services, you only have one contact partner for both.

You do not have to contact an additional testing institution and benefit from our deep understanding of your lighting solutions. We know the components and can help you to fulfill the normative requirements. Moreover, we offer competitive lead times and prices. In case of urgency, we are able to offer an express service based on availability and with additional fees.

Available tests
You can choose specific individual tests or complete certification packages.

Individual tests
The following list shows all the tests we currently offer. You will receive a quotation based on your individual needs as every project is different and prices need to be estimated on a case-by-case basis.

EN 60598Full electrical safety report for simple luminaire without
additional requirements
EN 60695-2-10, EN 60695-11-5,
EN 60112, EN 60695-10-2, EN 60068-2-11
Fire hazard material tests – glowing/hot wire, needle flame, PTI
(insulating materials), abnormal heat (ball pressure), corrosion
tests (salt mist)
Electromagnetic compliance
EN 61547Immunity
EN 55015EMI measurements in chamber and loop antenna
EN 61000-3-2Harmonics, power factor
EN 61000-3-3Flicker (> 600 W)
EN 13032-4, EN 62717, IEC 62722-2-1Lumen output/total flux
IEC/TR 62778, IEC 62471Eye safety
EN 13032-4, EN 62717, IEC 62722-2-1Goniometer measurements
Mechanical, IP & ERP tests
IEC/EN 60068Vibration mechanical test
IEC 60529IP test (moisture and dust)
ERP: 1194, 1428, 13032Stand-by power

Test packages

We also offer complete packages in cooperation with the VDE Institute, where OSRAM does the testing for obtaining the VDE Certification marks.

The certification sovereignty remains with the VDE Institute alone.

Luminaire CE testing
EN 60598 + EMC
Luminaire EMC VDE mark
EN 55015
Luminaire VDE mark
EN 60598
Deutsche Akkreditierungsstelle
DAkkS flexible accreditation scope
ILAC Accredia (Treviso LAB)
Accreditation scope

How you can order tests

Please contact your local sales representative (e.g. Key Account Manager) to inquire prices, availabilities and lead times for a specific testing service.

After your project has been evaluated, we will send you the price quotation and lead times. Once the project has started and the tests are done, your contact person will send you the results.

Material test: Needle flame tester
Climatic chambers/air shock chambers
